LCD Magnetic Hotplate Stirrer LMHS-A103

Specifications :

Work plate Dimension [W x D]	184 x 184 mm
Max. Stirring Capacity	20 L
Stirring positions	1
Work plate material	Glass ceramic
Max. magnetic bar length	80 mm
Speed range	100 – 1500 rpm
Resolution	± 1 rpm
Speed display	LCD
Temperature display	LCD
Heating temperature range	Room Temp. to 550 °C (Increment 1 °C)
Permissible ambient temperature and humidity	5 – 40 °C, 80 % RH
Temperature control accuracy	± 1 °C (< 100 °C) ± 1 % (> 100 °C)
Overheating protection	580 °C
Temperature display accuracy	± 0.1 °C
External temperature sensor	PT1000 (Accuracy ± 0.2 °C)
"Hot" warning	50 °C
Data connector	RS232
Protection class	IP21
Motor type	Brushless DC motor
Motor rating input	18 W
Motor rating output	10 W
Heating output	1000 W
Power	1050 W
Voltage	100 – 120 / 200-240 V, 50 / 60 Hz
Dimension [W x D x H]	215 x 360 x 112 mm
Weight	5.3 kg

Features :

• -  Stirring range from 100 - 1500 rpm
• -  Max. stirring quantity is 20 L
• -  Built-in PID controller ensures safe heating of the medium with Overheating protection
• -  Max. heating plate temperature 550 °C
• -  Glass ceramic work plate for chemical resistant performance and efficient heat transfer
• -  Rotating knobs enable easy adjustment of speed and temperature
• -  Remote function provides PC control and data transmission
